Год начала выпуска: 1986
Регион: Америка
GENERAL SPECIFICATIONS
Power supply:
AC: 120V 60 Hz
DC: 9V ["D" cell (IEC R20) x 6 or equivalent]
Power consumption: 11W
Speakers: 100mm dynamic x2
15mm piezo-electric type x2
Dimensions: 194.5(H) x 542(W) x 135(D) mm
Weight: 2.8 kg (with batteries)
RADIO SECTION
Circuit system: FM/AM 2-band superheterodyne
Tuning range: FM: 88 to 108 MHz
AM: 526.5 to 1606.5 kHz
Antenna (aerials): FM: Telescopic antenna (aerial)
AM: Built-in ferrite-core antenna (aerial)
TAPE RECORDER SECTION
Tape: Cassette tape
Tape speed: 4.8 cm/s
Recording system: DC bias ...
Erasing system: Magnet erase ...
Playback frequency range:
60 to 12,000 Hz (Normal tape)
JACK:
External microphone: 2 mV, 6 kohms
Output level and load impedance:
Headphones: 8 to 100 ohms
speakers jack x 2
Specifications are subject to change for performance improvement without notice.
|
