JVC 1927 . : ,





JVC RC-880 JW



: 1984


SPECIFICATIONS

Speakers : 12 cm (5") x 2,

5 cm (2") x 2

Frequency ranges : FM 88-108 MHz

AM 540-1600 kHz

SW1 2.3 - 7 MHz

SW2 7-22 MHz

Antennas : Telescopic antenna for FM&SW

Ferrite core antenna for AM & SW1

Track system : 4-track 2-channel stereo

Motors : Electronic governor DCmotor for capstan


Tape speed : 4.8 cm/sec (1-7/8 inch/sec)


Frequency response : 50 —15,000 Hz (with metal tape)

50 14,000 Hz (with chrome tape)

50 12,500 Hz (with normal tape)

Signal-to-noise ratio : 54 dB (weighted, at 1 kHz, 3 % THD with metal tape) Improved by 5 dB at 1 kHz and by 10dB at 5 kHz or more with ANRS/DOLBY B NR ON

Wow and flutter : 0.09 % (WRMS)

Fast forward time : Approx. 120 sec. (C-60 cassette)

Rewind time : Approx. 120 sec.(C-60 cassette)

Input terminals : MIC x 2 (Min. input level: 0.7 mV(- 63 dBV) Matching impedance: 200 ohm - 2 kohm)

Power output : 5 watts per channel, min.RMS,

Power sources : AC 240-220/120-110 V,50/60 Hz

DC 12 V(D size R20 x8)

Power consumption : 28 watts (with power switch on)


Dimensions :


Weight : Approx.
