Год начала выпуска: 1974
Регион: Азия
SPECIFICATIONS
Power source: AC 105/120/210/240 Volt 50/60Hz switchable
DC 9V (UM-1,dry sell x 6)
12Volt (car battery)
Speakers: 165 mm 4 ohms
Output power:
MPO 8W(4W+4 W) AC operation
RMS;5W( 2.5W + 2.5W )
(DC operation, 10% distortion)
Dimensions: Width; 416 mm
Depth; 196 mm
Height; 254 mm
Weight: 6.8 kg without batteries
TAPE SECTION
Tape: Compact cassette tape
Tape speed : 4.76cm/sec
W&F: 0,1 % WRMS
Frequency response: 70 Hz — 10,000 Hz
Crosstalk : 36dB
Separation: 36dB
S/N ratio: 45dB
Input sensitivity and impedance:
External mic;600 ohms
Record\Playback
socket(AMP); 0.6mV/5.6k ohms
Output impedance: Headphones; 8ohms -25 ohms
RADIO SECTION:
Frequency range: FM; 88MHz - 108 MHz
MW; 535kHz - 1,605 kHz
SW1 3.0- 9.0MHz
SW 2 9.0-24.0MHz
Sensitivity: MW 45dB/m
SW1 45dB/m(30dB)
SW2 45dB/m(30dB)
FM 20dB
|
