Akai GXC-735 D



: 1979


TECHNICAL DATA
TRACK SYSTEM 4 Track, 2 channel stereo system
TAPE Philips type cassette tape
TAPE SPEED 4.76cm/sec 1-7/8 ips
WOW & FLUTTER Less than 0.045% WRMS. 0.12% (DIN45500)
FREQUENCY RESPONSE
35 to 14,000 Hz ±3 dB at LN position
35 to 14,000 Hz 3 dB at LH position
35 to 15,000 Hz +3 dB at CrO2,(SA) position
35 to 16,000 Hz 3 dB at FeCr position
DISTORTION
Less than 1.0% at LN position (1000Hz 0VU)
Less than 1.0% at LH position
(1000Hz 0VU)
Less than 1.5% at CrO
2position(1000Hz 0VU)
Less than 1.5% at FeCr position
(1000Hz 0VU)
SIGNAL TO NOISE RATIO
Better than 55 dB using LN tape
Better than 55 dB using LH tape
Better than 56 dB using Cr02 (SA) tape
Better than 56 dB using FeCr tape
Dolby NR switch ON: Improves up to 10 dB above 5 kHz
ERASE RATIO Better than 65 dB
BIAS FREQUENCY 85 kHz
HEADS 3 head system (one GX recording/playback head and Two erase head)
MOTORS 2: One Electronically Speed Controlled DC motor for Capstan Drive
One DC Motor for Reel Drive)
F.F. & REWIND TIME 60 sec, using a C-60 Tape
OUTPUT JACKS
Line (2): 410mV(OVU)
Required load impedance: more than 20 kohms
Phone (1): 100 mV/8 ohms
INPUT JACKS Microphone (2): 0.25mV (input impedance 5 kohms)
Required microphone impedance: 600 ohms
Line (2): 70 mV (input impedance 100 kohms)

POWER REQUIREMENTS

110-120V/220-240V, 50/60 Hz

DIMENSIONS 440(W) x 290
(D)x 150(H)mm (17.3 x 11.4 x 5.9) inches
WEIGHT 9.7 kg (21.4 lbs)

:
Akai GXC-735 D 100volt
