Akai GXC-715 D



: 1979


TECHNICAL DATA
TRACK SYSTEM 4 Track, 2 channel stereo system
TAPE Philips type cassette tape
TAPE SPEED 4.76cm/sec 1-7/8 ips
WOW & FLUTTER Less than 0.04% WRMS. 0.12% (DIN45500)
FREQUENCY RESPONSE
35 to 14,000 Hz ±3 dB at LN position
35 to 14,000 Hz 3 dB at LH position
35 to 15,000 Hz +3 dB at CrO2,(SA) position
35 to 16,000 Hz 3 dB at FeCr position
DISTORTION
Less than 1.0% at LN position (1000Hz 0VU)
Less than 1.0% at LH position
(1000Hz 0VU)
Less than 1.5% at CrO
2position(1000Hz 0VU)
Less than 1.5% at FeCr position
(1000Hz 0VU)
SIGNAL TO NOISE RATIO
Better than 56 dB using CrO2(SA), position (DIN 45500)
Dolby NR switch ON: Improves up to 10 dB above 5 kHz
ERASE RATIO Better than 65 dB
BIAS FREQUENCY 85 kHz
HEADS 2 head system (one GX recording/playback head and one erase head)
MOTORS 2: One Electronically Speed Controlled DC motor for Capstan Drive
One DC Motor for Reel Drive)
F.F. & REWIND TIME 70 sec, using a C-60 Tape
OUTPUT JACKS
Line (2): 410mV(OVU)
Required load impedance: more than 20 kohms
Phone (1): 100 mV/8 ohms
INPUT JACKS Microphone (2): 0.3 mV (input impedance 5 kohms)
Required microphone impedance: 600 ohms
Line (2): 70 mV (input impedance 100 kohms)

POWER REQUIREMENTS
120V/60 Hz for U.S.A. & Canada
240V/50 Hz for Australia,
100V, 50/60 Hz for Japan
110-120V/220-240V, 50/60 Hz for other countries
DIMENSIONS 440(W) x 273
(D)x 138(H)mm (17.3 x 10.8 x 5.4) inches
WEIGHT 8.5 kg (18.8 lbs)
NOTE:
Standard reference tapes
LN position: AKAl C-60LN, FUJI FL C-60
LH position: MAXELL UD C-60 CrO, position: TDK SA C-60
FeCr position: SONY Duad C-60
* For improvement purposes, specifications and design are subject to change without notice. * "Dolby" and the Double D symbol are trademarks of Dolby Laboratories. (Manufactured under license from Dolby Laboratories.)
