Год начала выпуска: 1978
Регион: Европа
TECHNICAL DATA
TRACK SYSTEM 4 Track, 2 channel stereo system
TAPE Philips type cassette tape
TAPE SPEED 1-7/8 ips
WOW & FLUTTER Less than 0.06% WRMS. 0.17% (DIN45500)
FREQUENCY RESPONSE
35 to 15,000 Hz ±3 dB at LN position
35 to 16,000 Hz +3 dB at CrO, position
35 to 19,000 Hz ±3 dB at FeCr position
DISTORTION
Less than 1.0% (1000Hz "0" VU using at LN tape)
SIGNAL TO NOISE RATIO
Better than 51 dB at CrO2, position (DIN 45500)
Dolby NR switch ON: Improves up to 10 dB above 5 kHz
ERASE RATIO Better than 70 dB
BIAS FREQUENCY 100 kHz
HEADS 3 head system (one GX recording/playback head and one erase head)
MOTORS 3 motor system (one DC FG servo motor for capstan drive and two DC motors for reel drive)
F.F. & REWIND TIME 70 sec, using a C-60 Tape
OUTPUT JACKS
Line (2): 0.775 V(0 VU)
Required load impedance: more than 20 kohms
Phone (1): 50 mV/8 ohms
INPUT JACKS Microphone (2): 0.3 mV (input impedance 2.4 kohms)
Required microphone impedance: 600 ohms
Line (2): 70 mV (input impedance 100 kohms)
SEMICONDUCTORS Transistors: 82, Diodes: 125, FETs: 8, ICs: 8
POWER REQUIREMENTS
120V/60 Hz for U.S.A. & Canada
240V/50 Hz for Australia,
100V, 50/60 Hz for Japan
110-120V/220-240V, 50/60 Hz for other countries
DIMENSIONS 440(W) x 306(D) x 142(H) mm (17.3 x 12 x 5.6) inches
WEIGHT 11.1 kg (24.4 lbs)
