История фирмы AKAI началась в июле 1929 г. Фирма выпускала множество различных устройств включая электромузыкальные инструменты и медицинскую технику. В начале 90-х годов была продана, в связи с появившимися финансовыми проблемами.
Подробнее о производителе
Глоссарий аббревиатур
|
|
|
Год начала выпуска: 1984
Регион: Европа
Specifications
Track System....................4 Track 2 Channel Stereo System
Tape.............................Philips Type Cassette
Tape Speed......................4.76 cm/s ± 1.0% (1 -7/8 ips. ± 1.0%)
Heads...........................Erase Head x 2
Super GX head for recording x 1
Super GX head for playback x 1
Motors...........................FG servo D.C. motor for direct capstan drive x 2
D.C. motor for reel drive x 1
Wow & Flutter....................0.08% WTD (DIN), 0.028% WRMS
Tape Winding Time..............90 sec. using a C-60 cassette tape
Frequency Response............Normal: 20 to 18,000 Hz ±3 dB (-20 VU)
Cr02: 20 to 19,000Hz ±3dB(-20VU)
Metal; 20 to 21,000 Hz ±3dB (-20 VU)
Signal to Noise Ratio.............Metal: Better than 60 dB
(measured via tape with peak recording level)
Dolby B-type NR switch ON: Improves up to 5 dB at 1 kHz,
10 dB above 5 kHz
Dolby C-type NR switch ON: Improves up to 15 dB at 500 Hz, 20dBat 1 kHz to 10 kHz
Harmonic Distortion..............1 kHz, 3rd harmonic distortion
Metal: Less than 0.7%
Input............................Line in: 70 mV (input impedance: 47 kohms)
Output...........................Line out: 410 mV at 0 VU
Required load impedance: more than 20 kohms
Phone: 1.3mW/8ohms at 0 VU
Power Requirements.............120V, 60 Hz for USA and Canada
220V, 50 Hz for Europe except UK
240V, 50 Hz for UK and Australia
110V/120V/220V/240V, 50/60 Hz switchable for other countries
Dimensions......................440(W) x 105(H) x 372(D)mm
(17.3x4.1x14.6")
Weight...........................7.6 kg
STANDARD ACCESSORY
Connection Cords............................................................1 set
For improvement purposes, specifications and design are subject to change without notice.
|
|
|
|
|
