Panasonic RX-DS660



: 1990


Radio Frequency range
FM 87.50-108.00 MHz
LW 146-288 kHz
MW 522-1611 kHz

CD player
Sampling frequency 44.1kHz
Decoding 16 bit linear
Beam source Semiconductor laser (wavelength 780 nm)
No. of channels 2 channel, stereo
Frequency response 20 Hz-20 kHz
Wow and flutter Less than possible measurement data


Tape recorder
Track system 4 track, 2 channel, stereo
Recording system AC bias
Erasing system AC erase
Monitor system Variable sound monitor

Frequency range
Normal 30-16000 Hz
Cr02 30-17000 Hz


General
Power requirement
AC 220-240 V, 50 Hz,
Battery ; 15 V (Ten UM-1, R20/LR20 batteries)
Memory back-up for computer/clock
6 V (Four UM-3, R6/LR6 batteries)
DC in 13.2V
Power Consumption; 45 W (AC only)

Power Output ; 30Wx2....PMPO
16Wx2....MPO


Speakers
2 Woofer 16 cm (2.7
Ω)

2 Tweeter 2 cm

Jacks Input Mix. MIC; 5 mV (4.7 kΩ)
AUX; 200mV(47kΩ)
FM Ant;75Ω
Output HEADPHONES; 32Ω(3.5
)
Speakers;2.7-8Ω

Dimensions (WXHXD) 702x229x218 mm
Main unit; 349(W)x229(H)x218(D)

Speaker Box ; 185(W)x218(H) x183(D)

Weight 7.1 kg without batteries
