Panasonic RX-C34 L



: 1987


SPECIFICATIONS
<RADIO>
Radio Frequency Range:
FM; 87.5-108 MHz
LW; 148.5-285 kHz
MW; 520-1610 kHz
SW; 5.9-18.0 MHz
<TAPE RECORDER>-
Frequency Range:
80-8000 Hz (with normal tape)

Recording System: DC bias, Magnet erase
Tape Speed: 4.8 cm/s
Track System: 4-track 2-channel stereo


<GENERAL>
Power Requirement: AC; 220 V, 50 Hz
Power consumption; 15 W Battery; 9 V (six UM-1, "D" size batteries)
Car Battery; with optional car battery cord RP-9550

Power Output: 8W (4Wx2)…RMS

Speakers:
Woofer; 12 cm PM Dynamic Speaker) (3Ω )
Tweeter; 3 cm Ceramic Speaker (300Ω )

Jacks:
Input;
LINE IN; sensitivity 280 mV/47 kOhm.

Output; EXT SP; 3 Ohm
HEADPHONES; 32 Ohm (8-50 Ohm)

Dimensions: (WxHxD) 510x194x155 mm
Main unit; 267x194x134 mm
Speaker box;125x194x134 mm
Weight: 3.2 kg without batteries
