Panasonic RX-F4



: 1984


SPECIFICATIONS

<RADIO>
Radio Frequency Range:
FM; 88-108 MHz

AM; 525-1610 kHz


Frequency Range:
80-12000 Hz (with normal tape)

Recording System: DC bias,

Erasing system Magnet erase
Track System: 4-track 2-channel stereo recording and playback

Tape speed: 4.8 cm/s


PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD and
REWIND TIME: Approx. 110 seconds with C-60 cassette tape

Power Requirement:
<GENERAL>
Power Requirement:
AC; 120 V, 50/60 Hz

Power consumption; 12W (AC only)

Battery; 9 V (six "C", size flashlight batteries)


Power Output: 8W (4Wx2)...(RMS max)
Speaker: Woofer;10cm PM dynamic speaker 3Ω

Tweeter; 1cm PM dynamic speaker(1.3kΩ)

Jacks:
Input;
MIC; sensitivity 0.25 mV/applicable microphone impedance

200-600 Ohm (recommended microphone RP-8135)

Output; HEADPHONES; 32 Ohm


Dimensions: (WxHxD)465x177x108 mm

Weight: 2.1 kg without batteries
(not included)
