Akai GX-9 100 volts



: 1985


Specifications
Track System.............Compact cassette stereo
Motors....................FG servo direct drive motor for
capstan drive x 1
DC motor for reel drive x 1
DC motor for mechanism drive x 1
DC motor for cam & door drive x 1
Heads.....................Super GX head for recording x 1
Super GX head for playback x 1
Erase head x 1
Wow & flutter..............0.025% (WRMS), 0.04% (DIN)
Distortion................. 0.6% (Metal)
Frequency response.......Metal: 20 Hz to 21,000 Hz ±3 dB
Chrome: 20 Hz to 20,000 Hz ±3 dB
Normal: 20 Hz to 19,000 Hz ±3 dB
S/N....................... Metal: 60dB
Dolby C type NR ON: Improves up
to 15 dB at 500 Hz, 20dB at 1 kHz
to 10 kHz
Dolby B type NR ON: Improves up
to 5 dB at 1 kHz, 10 dB above 5 kHz
Input......................LINE IN: 70 mV/47 kohms
Output....................LINE OUT: 410 mV/1 kohms
PHONES: 1.3 mW (8 ohms)/83.2 ohms
Power requirements.......
100 V, 50/60 Hz 28W
Dimensions................440 (W) X105 (H) x372 (D) mm
(17.3x4.1 x 14.6 inches)
Weight....................7.0 kg (15.4 lbs)
* For improvement purposes, specifications and design are subject to change without notice.

Standard reference tapes
Types of Tape Recommended Tapes
Normal Position MAXELL UD*
CrO2 Position TDK SA
Metal Position TDK MA*
* C-60 tapes with this mark are the standard reference tapes.


:
AKAI GX-9
