RMG International B.V. Professional Audio LPR 35 (mod.34520)

AKAI 1929 . . 90- , .




AKAI AM-U3



: 1984


Specifications
Power amplifier section
Rated Power Output
(2 channels Driven)...... 8 ohms 4 ohms
20 Hz to 20 kHz.......... 45W x 2/0.02% 45 W x 2/0.05%
1 kHz.................. 48W x 2
Music Power............ 110W x 2
Power Band Width
(IHF -3 dB, 8 ohms)..... 10 Hz to 60 kHz/0.5%
Signal to Noise Ratio
PHONO................ 78 dB
AUX/TUNER/TAPE..... 100 dB
Residual Noise
(8 ohms, IHF-A)......... 300
μV
Channel Separation
(1kHz)................. 60 dB
Damping Factor
(1 kHz, 8 ohms) ......... 50
Output
Required Speaker Impedance
SPEAKERS.............4 ohms to 16 ohms (A or B)
8 ohms to 16 ohms (A and B)
Pre amplifier section
Input Sensitivity/Impedance
PHONO................ 2.5 mV/47 kohms
AUX................... 150 mV/47 kohms
TUNER................ 150 mV/47 khoms
TAPE PLAY............150 mV/47 khoms
Output Level
TAPE REC.............150 mV/1 kohm
Frequency response PHONO (RIAA Deviation) 20 Hz to 20 kHz (± 0.5 dB)
TUNER/AUX/TAPE.....5 Hz to 80 kHz (-3 dB)
Tone Control
BASS.................. ±8 dB/100Hz
TREBLE................±8 dB/10 kHz
Subsonic Filter.............-3 dB/oct at 18 Hz
Phono Maximum Input
Level (1 kHz) ...........60 mV
Power Requirement........120V, 60 Hz for USA and
Canada
220V, 50 Hz for Europe
except UK
240V, 50 Hz for UK and
Australia
110V/120V/220V/240V
switchable 50/60 Hz for
other countries.
Dimensions...............440(W) x 98(H) x 264(D) mm
(17.3 x 3.9 x 10.4 inchs)
Weight...................6.7 kg (14.7 lbs)
* For improvement purposes, specifications and design are subject to change without notice.
