Sharp GF-8989 E



: 1981


SPECIFICATIONS
Power Source: A C 110V ~ 120V and 220V ~ 240V, 50/60Hz
D C Internal (Batteries): Eight HP-2
DC External: 12V
Speakers: 16cm (6-1/2") woofer x 2: Horn type tweeter x 2
Output Power: MPO 16W (8W + 8W) on AC
RMS 9200mW (4,600mW + 4,600mW) on DC, 10% distortion
Semi Conductors: 7 IC's
37 transistors
25 diodes
8 LED's Dimensions:
Width; 510mm (20-1/16")
Depth; 134mm (5-1/4")
Height; 284mm (11-3/16)
Weight: 5.9 kg (13.0 lbs.) without batteries
TAPE RECORDER
Tape: Compact cassette tape
Frequency Response: 50Hz — 16,000Hz using METAL tape
Signal/Noise Ratio: 50dB (normal, Dolby NR off)
60dB (metal, Dolby NR on)
Wow and Flutter: 0.17% (CCIR)
Input Sensitivity and Input Impedance:
External Microphone; 600 ohms
Mixing Microphone; 600 ohms
Record/Playback Socket; 0.3mV/4.3k ohms
Output Level and Loaded Impedance:
Headphones; 8 ohms — 25 ohms
External Speakers; 3.2 ohms — 8 ohms
Record/Playback Socket; 0.65V, 50k ohms
RADIO
Frequency Range: LW; 150kHz- 285kHz
MW; 520kHz- 1620kHz
SW; 5.95MHz- 18MHz
FM; 87.6MHz- 108MHz

* Sharp reserves the right to make design and specification changes for product improvement. The performance specification figures indicated are nominal values of production sets. There may be some deviations from these values in individual units.


:
