Sharp GF-555 E



: 1980


SPECIFICATIONS (SHARP GF-555E)

GENERAL
Power source: AC 110/220/240V, 50/60Hz 40W

DC 15V (Ten UM/SUM-1, R20, HP-2, "D" batteries or external DC supply)


Speakers: 16cm (Woofer) 2;

5 cm (Tweeter) 2
Output power:

MPO 22W (11 W.+11W.) AC operation

RMS 12W ( 6W.+ 6W.) DC operation

10% Distortion


Semiconductors: 11-IC's (Integrated circuits)

32-Transistors

2-FET's

1-SCR

41-Diodes

26-LED's
Dimensions:

Width; 530mm

Depth; 150mm

Height; 320mm


Weight: 9 kg. (without batteries)

TAPE RECORDER/PLAYER
Tape: Philips-type compact cassette tape
Frequency response:

40Hz to 15000Hz (CrO2 tape)

40Hz to 12000HZ (normal tape)
S/N ratio: 50 dB


Wow and flutter: 0.17% (CCIR)


Input sensitivity and input impedance:

Ext. Mic; 600 ohms

Mixing Mic; 600 ohms

Line in; 0.1 V/100k Ohms
Output level and loaded impedance: Headphones; 8 ohms to 25 ohms

External speaker; 4 ohms to 8 ohms

Line out; 0.7V/50k Ohms

RADIO
Frequency range:

MW; 520 kHz to 1620 kHz

LW; 150kHz to 285 kHz

SW; 5.95 MHz to 18 MHz

FM; 87.6 MHz to 108MHz

:
