National RX-5600



: 1980


SPECIFICATIONS


RADIO FREQUENCY RANGE: FM; 76-108MHz
AM; 525-1605 kHz

Intermediate frequency: FM: 10.7 MHz

AM: 455 kHz


Sensitivity: FM; 1μV/m 50mW (S/N 6db)
AM; 70
μV /m / 50mW


POWER REQUIREMENT: AC; 100V(90
˜110 V), 50/60Hz
Power consumption; 14 W
Battery; 12 V (8-UM-1, "D" size batteries)
Car battery; with optional car battery cord RP-957
POWER OUTPUT: 10 W (5 Wx2) (EIAJ/DC.)
SPEAKERS: Woofer; 16 cmx2 PM dynamic speaker 3
Ω
Tweeter; 5 cm PM dynamic speaker 4
Ω
FREQUENCY RANGE: 40-12,000 Hz (with normal tape)
40-14,000 Hz (with FeCr tape)
40-14,000 Hz (with tape corresponding to CrO2 type)
40-17,000 Hz(with Metal tape)
Wow & Flutter: 0,055%(WRMS)

RECORDING SYSTEM: AC bias, AC erase
TAPE SPEED: 4.8cm/s.
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD and
REWIND TIME: Approx. 90 seconds With C-60 cassette tape
TRACK SYSTEM: 4-track 2-channel stereo recording and playback
JACKS:
INPUT; MIC; sensitivity 0.25 mV/applicable microphone impedance
200Ω
-600Ω (recommended microphone RP-8135)
MIX MIC; sensitivity 0.8 mV/applicable microphone impedance
200-600Ω

LINE IN; sensitivity 130 mV/47 kΩ
over
PHONO; sensitivity 3.9 mV/47 kΩ
over
OUTPUT; LINE OUT; sensitivity 0.42 V/2.2kΩ
under
EXTSP;3-8Ω

HEADPHONES; 8Ω
OTHERS; DC IN; 13.2V (12-15 V)
AC IN
EXT ANTENNA and EARTH
PHONO EARTH
DIMENSIONS: 563 mm (W) x 325 mm (H) x 139 mm (D)

WEIGHT: 7.5kg without batteries
Specifications are subject to change without notice.


:
