National RX-C 46 F



: 1984


SPECIFICATIONS
RADIO FREQUENCY RANGE: FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7.0-22.0 MHz

POWER REQUIREMENT: AC; 110-115/115-127/200-220/230-250 V, 50/60 Hz
240 V, 50 Hz only for Australia
Power consumption; 35 W Battery; 12 V (eight UM-1, "D" size batteries)
Car battery; with optional car adaptor,RP-952

POWER OUTPUT: 40 W(20 Wx2)...PMPO
15 W(7.5Wx2)...RMS(max.)
SPEAKERS:
Woofer; 10 cm PM dynamic speaker
Tweeter; 2 cm x 4 cm speaker

FREQUENCY RANGE:
60-14000 Hz (with normal tape)
60-15000 Hz (with Metal tape)

RECORDING SYSTEM: AC bias, AC erase
TAPE SPEED: 4.8cm/s
TRACK SYSTEM: 4-track 2-channel stereo recording and playback

JACKS:
INPUT; MIC; sensitivity 0.26 mV/applicable microphone impedance
200Ohm-600Ohm. (recommended microphone RP-V305)

LINE IN/CD; sensitivity 200 mV/47 kΩ

OUTPUT;
LINE OUT; sensitivity 420 mV/2.2 kΩ
EXT SP; 3-8Ω.
HEADPHONES; 32Ω

OTHERS; DC IN; 13.2 V
AC IN

DIMENSIONS: 557 mm x 176 mm x 188 mm
(W) x (H) x (D)

Main unit; 321 mm x 176 mm x 188 mm

Speaker box; 120 mm x 176 mm x 152 mm

WEIGHT: 4.6 kg without batteries

Specifications are subject to change without notice.


:
