Panasonic RX-F20 L



: 1984


Specifications
General
Power requirement: AC;220V 50Hz\60Hz with AC adapter

Battery; 9V (six- "D" size Flashlight batteries)
Panasonic UM-1 or equivalent
Car battery; with optional car adaptor RP-917
Power consumption; AC adapter only(10W)
Power output: 3.5
Wx2 ... MPO (music)

3.5 Wx2 ... RMS (max)

Speakers: Woofer 10cm PM dynamic speaker

Input: MIC; sensitivity 0.25mV/applicable microphone
impedance 200-600Ω
DC in 9 V


Output: Ext. Sp.
3Ω-8Ω
Headphones:320mW\32Ω

REC/PB Connection 5 pin REC\PLAY DIN type
IN; 0.27mV\2.7kΩ
OUT;420mV (470kΩ under)


Dimensions: Total size
400mm(W) x 127mm(H) x 96mm(D)

Weight: 1.95kg (without batteries)

Radio section

Radio frequency range: FM; 87.5-108 MHz
LW; 150-285 kHz
MW; 520-1610 kHz
SW; 5.9-18.0 MHz




Tape Deck Section
Frequency responce: 9
0-10,000 Hz(with normal tape)
60-10,000 Hz(with CrO2 tape)
60-12,000Hz (with Metal tape)

Recording system; AC bias, AC erase

Tape speed: 4.8cm/s
Wow&Flutter 0.3%(WRMS)
Program time: 1 hour with C-60 cassette tape

Track system: 4-track stereo recording and playback
