История фирмы AKAI началась в июле 1929 г. Фирма выпускала множество различных устройств включая электромузыкальные инструменты и медицинскую технику. В начале 90-х годов была продана, в связи с появившимися финансовыми проблемами.
Подробнее о производителе
Глоссарий аббревиатур
|
|
|
Год начала выпуска: 1981
SPECIFICATIONS
Turntable...............Aluminum alloy die cast
Drive System &
Mechanism.............Quartz locked direct drive,
Autoreturn
Motor...................DC servo
Speed & Pitch Control.. 33-1 /3,45 rpm ±5%
Speed Deviation........Less than ±0.003%
Wow & Flutter...........0.05% (DIN), 0.035% (JIS)
Rumble.................45 dB (DIN A), 70 dB (DIN
B)
Tone Arm...............S-shaped Static Balanced
Effective Arm Length ... 220mm Stylus Pressure Adjustment Range.............0 to 3 grams
Applicable Cartridge
Weight..................4 to 12 grams
Arm Lifter...............Oil damped
Overhang...............15 mm
Offset Angle............22°30'
Horizontal Tracking
Error Angle..............+ 3°5 , -1 °13 '
Shell Weight............8.2 grams
Cartridge................VM (Dual Magnet) type
[Model AP-Q55 does not include cartridge]
Optimal Stylus
Pressure..............2 grams
Output Voltage........5 mV
Channel Separation .. More than 20 dB (DIN)
Frequency Response . 0 dB at 1 kHz,
±2 dB at 10 kHz
Static Vertical
Compliance...........17.7 x 10 _6 cm/dyn
Static Horizontal
Compliance...........29.1 x 10 "6 cm/dyn
Power Requirements.... 120V, 60 Hz for USA and
Canada
220V, 50 Hz for Europe
except UK
240V, 50 Hz for UK and
Australia
110-120V/220-240V,
50/60 Hz switchable
for other countries Dimensions.............440 (W) x 140 (H) 403 (D)
mm
(17.3x5.5x15.8 inches) Weight..................5.7 kg (12.6 lbs)
STANDARD ACCESSORIES
45 rpm Adapter....................................1
Screwdriver........................................1
Operator's Manual.................................1
OPTIONAL ACCESSORIES
Replacement Stylus...........................RS-90
Akai Cleaning Kit............................CK-200
* For improvement purposes, specifications and design are subject to change without notice.
DL TYPE TURNTABLE
* DL type turntables are not equipped with dust cover or hinges.
* Dust cover and hinges are not necessary when placing the DL type turntable inside an audio rack with a special section for turntable.
|
|
|
|
|
