Panasonic RX-FW 20 L



: 1986


SPECIFICATIONS


RADIO FREQUENCY RANGE: FM; 87.5-108 MHz
LW; 150-285 kHz
MW; 520-1610 kHz
SW; 5.9-18.0 MHz


POWER REQUIREMENT: AC; 220 V, 50HZ
Power consumption; 14 W (240 V, 50 Hz
Power consumption; 14 W)
Battery; 9 V (six UM-1, "D" size batteries)
Car battery; with optional car adaptor RP-917

POWER OUTPUT: 16 W(8 Wx2)...PMPO
8W(4Wx2)...RMS max.

SPEAKERS: Woofer; 10 cm PM dynamic speaker
Tweeter; 2.0 cm speaker

FREQUENCY RANGE: 60-13000 Hz
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8cm/s
TRACK SYSTEM: 4-track 2-channel stereo

JACKS:
INPUT; MIXING MIC; sensitivity 5 mV applicable microphone
impedance 200Ω-600Ω (recommended microphone RP-V305)
LINE IN; sensitivity 224 mV/47 k
Ω
OUTPUT; HEADPHONES; 32 Ω

DIMENSIONS:
(WxHxD) 492x126x100mm
WEIGHT: 2.6 kg without batteries
Design and Specifications are subject to change without notice.


:
Panasonic RX-FW20
National RX-FW20 F
National RX-FW20 F black
