Panasonic RX-DT680



: 1991


Radio Frequency range
FM 87.50-108.00 MHz
LW 146-288 kHz
MW 522-1611 kHz


CD player
Sampling frequency 44.1kHz
Decoding 16 bit linear
Beam source Semiconductor laser (wavelength 780 nm)
No. of channels 2 channel, stereo
Frequency response 20 Hz-20 kHz
Dynamic range; 86dB
S/N 95dB
Wow and flutter Less than possible measurement data


Tape recorder
Track system 4 track, 2 channel, stereo
Recording system AC bias
Erasing system AC erase
Monitor system Variable sound monitor


Frequency range
Normal 20-16000 Hz
Cr02 20-17000 Hz


General
Power requirement
AC 230-240 V, 50 Hz,
Battery ; 15 V (Ten UM-1, R20/LR20 batteries)
Memory back-up for computer/clock
6 V (Four UM-3, R6/LR6 batteries)
DC in 13.2V
Power Consumption; 57 W (AC only)

Power Output ; Woofer 60W(30Wx2)....PMPO
Tweeter 20W(10Wx2)....PMPO


Speakers
Woofer 12 cm x2 PM Dynamic Speaker (2.7
Ω)

Tweeter 8 cm x2 PM Dynamic Speaker (8Ω)

Jacks Input Mix. MIC; 5 mV (200-600Ω)
AUX; 200mV(47kΩ)
FM Ant;75Ω
Output HEADPHONES; 32Ω(3.5
)
Speakers;LOW2.7-8Ω
HIGH8-16Ω
CD OUT

Dimensions (WXHXD) 641x267x232 mm
Main unit; 313(W)x267(H)x232(D)

Speaker Box ; 174(W)x254(H) x188(D)

Weight 8.7 kg without batteries
