Panasonic RX-C39 L



: 1984


SPECIFICATIONS

<GENERAL>
Power Requirement: AC; 220-240V 50 Hz
Power consumption; 30 W (AC only)
Battery; 12 V (eight "D" size batteries)

Power Output: 18(9Wx2)MPO

14(7,5Wx2)...RMS(max.)

Speakers: Woofer;(12cm)x2) PM Dynamic Speaker(3Ω)

Tweeter; (2 cmx 4cm)
PM Dynamic Speaker (1.4 kΩ)


Input;
MIX MIC; sensitivity
0.8 mV/applicable microphone impedance
200-600 Ohm∅3.5mm
CD/LINE IN; sensitivity
330 mV/50 kOhm.
DC IN 13.2V
O
utput; EXT SP; 3-8 Ohm
HEADPHONES; 32 Ohm


Dimensions: (WxHxD)540x208x162 mm
Main unit; 277x20
8x135 mm

Speaker box; 134x208x135 mm

Weight: 3.8 kg without batteries

<RADIO>
Radio Frequency
Range: FM; 87.5-108 MHz
LW; 148.5-285 kHz
MW; 520-1610 kHz
SW; 5.9-18.0 MHz
z
Intermediate

Frequency FM; 10.7 MHz

AM; 455 kHz
<TAPE RECORDER>-
Frequency Responce:


90-13000 Hz (with CrO2 tape)

90-10000 Hz (with normal tape)

Recording System: AC bias, Magnet erase
Tape Speed: 4.8 cm/s
Track System: 4-track 2-channel stereo
