Matsushita Electric Industrial , Ltd. (MEI), Panasonic, National, Technics Quasar, , .





National RX-CW55 F



: 1987


SPECIFICATIONS
<RADIO>
Radio Frequency Range:
FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7.0-22.0 MHz
<TAPE RECORDER>
Frequency Range: 60-12000 Hz (with normal tape)
60-13000 Hz (with Cr02 type tape)
Recording System: AC bias, Magnet erase
Tape Speed: 4.8 cm/s
Track System: 4-track 2-channel stereo
<TIMER/CLOCK>
Power Requirement: Battery; DC 1.5 V (one UM-3, "AA" size battery)
Accuracy: ±20 seconds (25°C)
<GENERAL>
Power Requirement: AC; 110-127/200-220/230-250 V, 50/60 Hz
Power consumption: 38 W / 240 V, 50 Hz
\ Power consumption; 35 W / Battery; 15 V (ten UM-1, "D" size batteries)
Car Battery; with optional car battery cord RP-9550
Power Output: 60 W (30 Wx2).. PMPO
28 W (14 Wx2).. .RMS (max.)
Speakers: Woofer; (10 cmx10 cm AFD speaker)x2
Tweeter; 2 cm speakerx2
Passive Radiator; 5 cmx13 cm
Jacks:
Input; MIX MIC; sensitivity2.2 mV/applicable microphone impedance
200-600
Ω (recommended microphone RP-V305)
CD/LINE IN; sensitivity 400 mV/50 k
Ω
Output; EXT SP; 3 Ω.
HEADPHONES; 32
Ω(8-50 Ω)
Dimensions: 725 x 163 x 188 mm
(W x H x D) Main unit; 355 x 163 x 188 mm
Speaker box; 191 x163x168 mm
Weight: 6.0 kg without batteries






:
Panasonic RX-CW55 L 65-74 MHz
