Êîìïàíèÿ Matsushita Electric Industrial Ñî, Ltd. (MEI), íàèáîëåå èçâåñòíàÿ ñâîèìè òîðãîâûìè ìàðêàìè Panasonic, National, Technics è Quasar, ÿâëÿåòñÿ ìèðîâûì ëèäåðîì â ðàçðàáîòêå è ïðîèçâîäñòâå áûòîâîé ýëåêòðîíèêè è ýëåêòðîííîãî îáîðóäîâàíèÿ äëÿ øèðîêîãî êðóãà ïîòðåáèòåëåé, áèçíåñà è ïðîìûøëåííîñòè.
Ïîäðîáíåå î ïðîèçâîäèòåëå
Ãëîññàðèé àááðåâèàòóð
|
|
|
Ãîä íà÷àëà âûïóñêà: 1985
Ðåãèîí: Àçèÿ
SPECIFICATIONS
RADIO FREQUENCY RANGE: FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7.0-22.0 MHz
POWER REQUIREMENT: AC; 110-115/115-127/200-220/230-250 V, 50/60 Hz
RX-F10FA is 240 V, 50 Hz only
Power consumption; 14 W
Battery; 9 V (six UM-2, "C" size batteries)
POWER OUTPUT: 16 W (8 Wx2)...PMPO
9 W (4.5 Wx2)...RMS (max.)
SPEAKER: Woofer 10 cmx2 PM dynamic speaker
Tweeter 2 cmx2
FREQUENCY RANGE: 60-11,000 Hz (with normal tape)
60-12,000 Hz (with Cr02 type tape)
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8 cm/s
TRACK SYSTEM: 4-track 2-channel stereo
JACKS: INPUT; MIC; sensitivity 0.25 mV applicable
microphone impedance 200Ω-600Ω
(recommended microphone RP-8135)
LINE IN; sensitivity 250 mV/47 kΩ
AC IN
DC IN; 9 V OUTPUT; HEADPHONES; 32Ω
DIMENSIONS: 462 mm (W)x139 mm (H)x118 mm (D)
WEIGHT: 2.7 kg without batteries
Specifications are subject to change without notice.
|
|
|
|
|
