JVC 1927 . : ,





JVC RC-545 L



: 1979


SPECIFICATIONS

Semiconductors : 7 ICs (including 2 for the microphone),

12 transistors (including 2 for the motor)

14 Diodes

Speakers : 12cm(5") x 2

Tuner section

Frequency ranges : FM 88- 108MHz

SW 6 - 18MHz

MW 540 1600kHz

LW 150 -350kHz

Antennas : Telescopic antenna for SW &FM

Ferrite core antenna for MW & LW

Tape recorder section

Tape : Philips type cassette

Track system : 4-Track 2-channel stereo

Frequency response : 60—10,000Hz

Wow & flutter : 0.14% (WRMS)

S/N ratio : 40dB

Rewind time : Within 100 sec. (C-60 cassette)

Fast forward time : Within 100 sec. (C-60 cassette)

Amplifier section

Power output : Max. 5.4W (2.7W + 2.7W)(DC)

4W (2W + 2W) (DC) at 10% THD

Input jacks : Mic x 2 (0.8mV, low impedance)

Output jacks : Ext. speaker x 2 (load impedance3.2~8 Ohm), Headphones x 1

Input/output jack : DIN jack

Power supply : DC 9V (6 "R20" "U2" batteries)

AC 240/220/110V, 50/60Hz

Power consumption : 12W (RC-545L)

9.5W (RC-545LB)

Dimensions : 424(W) x 241(H) x 114(D)mm


Weight : 4.5kg(with batteries)
