Aiwa 1951 . 1967 . 2002 Aiwa - Sony, .

, ...





Aiwa CS-R50 L



: 1987


SPECIFICATIONS
Type Stereo multiband radio
cassette recorder
Power source Batteries, DC12V (R14PX8)
Household AC power (thru AC
adaptor)
Output 11.2W maximum (5.6W + 5.6W)
Speakers Woofer 100 mm cone type x2
Tweeter 20 mm ceramic type x 2
Tape Recorder Section
Built-in microphone Electret condenser microphone
Tape speed 4.8 cm/sec (1-7/8 ips)
Recording system AC bias
Erasing system AC erase
Recording time 90 minutes (C-90 cassette,
both directions)
Frequency response NORMAL tape: 40—12,500 Hz
CrO2 tape: 40—14,000 Hz
METAL tape: 40—16,000 Hz
Signal-to noise ratio 50 dB
Wow and flutter 0.14% (WRMS)
Radio Section
Frequency ranges FM: 87.5— 108 MHz
MW: 530—1,605 kHz
SW: 5.9— 18 MHz
LW: 150 - 285kHz
Antennas Whip antenna for FM and SW
Ferrite bar antenna for MW and LW
Dimensions (WXHXD) 500X147X139.5 (mm)
Weight 3.05 kg
Accessories AC adaptor X 1

The specifications and external appearance of this set are subject to change without prior notice.
