Sharp WF-340 H



: 1986


General
Power source: AC 110- 120V and
220-240V, 50/60HZ
DC 12V (UM/SUM-1 or R20 type x 8)
Output power: MPO; 10W(5W+5W)
(AC operation)

RMS; 7.6W
(3.8W + 3.8W) (DC operation)
Semiconductors: 7 ICs
10 Transistors 13 Diodes 2 LEDs
Dimensions: Width; 580mm
Height; 180mm
Depth; 135mm
Weight: 4.0 kg without
batteries
Tape Recorder

Tape: Compact cassette tape
Frequency response: 100Hz-10,000Hz
Signal/noise ratio: 55 dB (Deck 1, playback)
50 dB (Deck 2, recording)
Wow and flutter: 0.35% (DIN45511)
Input impedance: External mic: 600 ohms
Loaded impedance: Headphones; 8-32 ohms
External speakers; 4—8 ohms
Radio
Frequency range: FM; 87.6108MHz
SW 5.95-18MHz
LW; 150-285kHz
AM; 526.5-1,606.5kHz

Speaker
Speakers: 10cm woofer x 2
Horn type tweeter x 2
Impedance: 4 ohms
Maximum power handling capacity: 6.5W (maximum)
